Garmin GPSMAP 1223xsv SideVü, ClearVü and Traditional CHIRP Sonar with Worldwide Basemap
€3258.99
Product is orderable
-
12.1” x 8.9” x 3.2” (30.8 x 22.8 x 8.2 cm)
-
10.3" x 6.4"; 12.1" diagonal (26.2 x 16.3 cm; 30.7 cm diagonal)
-
1280 x 800 pixels
-
WXGA
-
3000.00
-
IPX7
-
2 microSD cards (back of unit)
-
5000
-
50000
-
50 saved tracks
-
100
-
10 Hz
-
Yes
-
-
-
-
-
-
-
-
-
-
Built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP)
-
1 kW
-
Built-in 260/455/800/1000/1200 kHz
-
-
10 - 32 Vdc
-
NMEA 2000 PORTS CONNECTIONS NMEA0183 INPUT PORTS NMEA 0183 INPUT (TX) PORTS VIDEO INPUT PORTS VIDEO OUTPUT PORTS HDMI J1939 PORTS GARMIN MARINE NETWORK PORTS 12-PIN TRANSDUCER PORTS 1 USB PORTS BNC EXTERNAL GPS ANTENNA PORT BLUETOOTH® CALLING ANT+ (CONNECTIVITY) GARMIN WI-FI NETWORK (LOCAL CONNECTION)
Garmin GPSMAP® 1223xsv
GET A SHARPER VIEW FROM YOUR CONNECTED HELM
With its sleek design, powerful processing and upgraded IPS display, this advanced 7”, 9” or 12” chartplotter integrates seamlessly into your Garmin marine system.
Easily integrate with more engines.
Connect to compatible third-party devices with OneHelm™ digital switching.
Easily build your marine system using the best of network connectivity.
Navigate any waters with preloaded mapping and coastal charts.
See below your boat with built-in sonar capabilities.
Manage your marine experience from nearly anywhere1.
See the world below.
ULTRA HIGH-DEFINITION SCANNING SONAR
Get built-in Ultra High-Definition SideVü and ClearVü scanning sonars with vivid, high-contrast color palettes to help distinguish fish from structure. GPSMAP® X3 series also supports 1 kW CHIRP traditional sonar capabilities.
PANOPTIX™ SONAR SUPPORT
Pair with Panoptix or LiveScope™ easy-to-interpret live sonar (transducer required, sold separately) to see all around your boat in real time.
Made for your helm.
FASTER, SHARPER, SMARTER
With its added processing power and new slimline design featuring edge-to-edge glass and a smaller unit footprint, it’s easy to retrofit this plotter in a wider range of dash configurations.
IMPROVED DISPLAY OPTICS
New higher-resolution IPS displays for 9” and 12” plotters offer improved sunlight readability and visibility from any angle, with 50% more pixels than previous-generation 9” GPSMAP devices.
Lorem ipsum olor sit amet
PRELOADED MAPPING
Experience unparalleled coverage and detail with preloaded BlueChart® g3 coastal charts and LakeVü g3 inland maps featuring integrated Garmin and Navionics® content and Auto Guidance3 technology.
OPTIONAL CHARTS AND MAPS
Bring a fresh new look and feel to your chartplotter with optional Garmin Navionics+™ or premium Garmin Navionics Vision+™ cartography featuring integrated coastal/inland content, access to daily updates, Auto Guidance+™ technology2 and more.
OPTIONAL RADAR BUNDLE
To help you avoid weather and traffic on the water, the compact 4 kW GMR™ 18 HD+ dome radar is available as a bundled option with your GPSMAP chartplotter/sonar package.
Sail and navigate with ease.
GARMIN SAILASSIST™ SAILING FEATURES
View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed, polars and more3.
OPTIONAL PREMIUM NAVIGATION FEATURES
These optional charts offer the best of Garmin and Navionics® data, Auto Guidance3 technology and other premium navigation features.
SAILING POLARS
Use the polar table to see key data, including how fast you should go at a certain wind angle and speed — so you know whether you need to adjust sail trim.
GARMIN MARINE NETWORK
If you have multiple compatible Garmin devices on your boat, you can share information — such as maps, user data, radar and IP camera video — among them.
NMEA 2000® AND NMEA 0183 NETWORKS
Connect to compatible autopilots, digital switching, weather, Fusion-Link™ audio system, media, VHF, AIS and more from one screen.
ACTIVECAPTAIN® APP
Built-in Wi-Fi® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Helm, Garmin Quickdraw™ Community data and more4.
INTEGRATED ANT® TECHNOLOGY
Connect with some of your favorite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers, GNX™ Wind marine instruments and wireless remote controls.
J1939 CONNECTIVITY
Now you can connect your chartplotter to different kinds of engines, including select Yamaha engines.
ONEHELM FEATURE
This feature brings together all the operations and capabilities of select third-party devices, such as EmpirBus™ digital switching, on one screen.
1 Requires ActiveCaptain app on your compatible smartphone paired to the GPSMAP 943xsv
2 Sold separately
3 Auto Guidance is for planning purposes only and does not replace safe navigation operations
4 When paired with a compatible smartphone
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
